ECS-ADN351
YDS
Intel Alder Lake, Intel Raptor Lake-P
VGA, HDMI
DDR4
SATA, M.2
YES
Supports 4G, Supports WIFI
Fanless
232, 422, 485
Support 4 USB3.0,2 USB2.0
205 mm ( length ) x1 40 mm ( width ) x5 5 mm ( height )
Operating temperature : -20°C to + 60 °C (optional: -40°C to + 70 °C )
WIN10, WIN11, Linux
Machine specifications
Technical Information | ||
Processor | Intel N95, 4C4T, up to 3.4 GHz 16 EU iGPU TDP: 15W Intel N97, 4C4T, up to 3.6 GHz 24 EU iGPU , TDP: 12W Intel N100, 4C4T, up to 3.4 GHz 24 EU iGPU , TDP: 6W Intel N200, 4C4T, up to 3.7 GHz , 32 EU iGPU , TDP: 6W Intel Core i3 N300, 8C8T, up to 3.8 GHz , 32 EU iGPU , TDP: 7W Intel Core i3 N305, 8C8T, up to 3.8 GHz , 32 EU iGPU , TDP: 15W Intel Atom X7425E, 4 cores and 4 processors, up to 3.4 GHz , 24 EU iGPU , TDP: 12W Intel N150, 4C4T, up to 3.6 GHz 24 EU iGPU , TDP: 6W Intel N250, 4C4T, up to 3.8 GHz , 32 EU iGPU , TDP: 6W Intel Core i3 N350, 8C8T, up to 3.9 GHz , 32 EU iGPU , TDP: 7W Intel Core i3 N355, 8C8T, up to 3.9 GHz , 32 EU iGPU , TDP: 15W Intel Atom X7211RE,2C2T, up to 3.2 GHz , 16 EU iGPU , TDP: 6W Intel Atom X7213RE,2C2T, up to 3.4 GHz , 16 EU iGPU , TDP: 9W Intel Atom X7433RE,4C4T, up to 3.4 GHz , 32 EU iGPU , TDP: 9W Intel Atom X7835RE,8C8T, up to 3.6 GHz , 32 EU iGPU , TDP: 12W | |
Memory | Supports one SO-DIMM DDR4 memory module, up to 32GB, with frequencies of 2133/2666/3200MHz . | |
Graphics processing | One HDMI port with a maximum resolution of 3840x2160 @ 60 Hz . 1 VGA port with a maximum resolution of 1920x1080 @60Hz | |
Network card | Supports 2 REALTEK 8111H 10/100/1000Mbit Ethernet | |
Storage | Supports one SATA 3.0 interface and one M.2 SSD ( M-Key 2280 SSD PCIe x1 /NGFF). | |
| mPCIE | Supports one M.2 WIFI ( E-Key 2230 PCIe x1) &USB2.0) Supports one M.2 4G/5G port ( B-Key 3042/3052 USB2.0 ) | |
| USB | Supports 4 USB 3.0 ports and 2 USB 2.0 ports. | |
Serial port | 4 RS232 (3-wire), 2 RS232 (3-wire ) / RS422 / RS485 | |
IO | Supports 8 GPIOs and 1 SIM card slot (optional). | |
Sound card | ALC662/ALC897 High-Fidelity Sound Card (Line-Out , MIC-in ) | |
Power supply | + 12V to + 19V voltage , + 12V is recommended. Power on (default ) , trigger power on ( optional ) . | |
Adapter | 60W or more | |
Temperature | Operating temperature : -20°C to + 60 °C (optional: -40°C to + 70 °C ) | |
Size | 205 mm ( length ) x1 40 mm ( width ) x5 5 mm ( height ) (overall dimensions except wall-mounted and external interfaces ) | |
Cooling system | Fanless design | |
Operating system | WIN10, WIN11, Linux | |
Weight | 1.46 kg (bare metal ) , 2.55 kg ( including packaging) | |
Color | The whole machine is gray, and the front and rear panels can be gray or black. | |
Machine specifications
Technical Information | ||
Processor | Intel N95, 4C4T, up to 3.4 GHz 16 EU iGPU TDP: 15W Intel N97, 4C4T, up to 3.6 GHz 24 EU iGPU , TDP: 12W Intel N100, 4C4T, up to 3.4 GHz 24 EU iGPU , TDP: 6W Intel N200, 4C4T, up to 3.7 GHz , 32 EU iGPU , TDP: 6W Intel Core i3 N300, 8C8T, up to 3.8 GHz , 32 EU iGPU , TDP: 7W Intel Core i3 N305, 8C8T, up to 3.8 GHz , 32 EU iGPU , TDP: 15W Intel Atom X7425E, 4 cores and 4 processors, up to 3.4 GHz , 24 EU iGPU , TDP: 12W Intel N150, 4C4T, up to 3.6 GHz 24 EU iGPU , TDP: 6W Intel N250, 4C4T, up to 3.8 GHz , 32 EU iGPU , TDP: 6W Intel Core i3 N350, 8C8T, up to 3.9 GHz , 32 EU iGPU , TDP: 7W Intel Core i3 N355, 8C8T, up to 3.9 GHz , 32 EU iGPU , TDP: 15W Intel Atom X7211RE,2C2T, up to 3.2 GHz , 16 EU iGPU , TDP: 6W Intel Atom X7213RE,2C2T, up to 3.4 GHz , 16 EU iGPU , TDP: 9W Intel Atom X7433RE,4C4T, up to 3.4 GHz , 32 EU iGPU , TDP: 9W Intel Atom X7835RE,8C8T, up to 3.6 GHz , 32 EU iGPU , TDP: 12W | |
Memory | Supports one SO-DIMM DDR4 memory module, up to 32GB, with frequencies of 2133/2666/3200MHz . | |
Graphics processing | One HDMI port with a maximum resolution of 3840x2160 @ 60 Hz . 1 VGA port with a maximum resolution of 1920x1080 @60Hz | |
Network card | Supports 2 REALTEK 8111H 10/100/1000Mbit Ethernet | |
Storage | Supports one SATA 3.0 interface and one M.2 SSD ( M-Key 2280 SSD PCIe x1 /NGFF). | |
| mPCIE | Supports one M.2 WIFI ( E-Key 2230 PCIe x1) &USB2.0) Supports one M.2 4G/5G port ( B-Key 3042/3052 USB2.0 ) | |
| USB | Supports 4 USB 3.0 ports and 2 USB 2.0 ports. | |
Serial port | 4 RS232 (3-wire), 2 RS232 (3-wire ) / RS422 / RS485 | |
IO | Supports 8 GPIOs and 1 SIM card slot (optional). | |
Sound card | ALC662/ALC897 High-Fidelity Sound Card (Line-Out , MIC-in ) | |
Power supply | + 12V to + 19V voltage , + 12V is recommended. Power on (default ) , trigger power on ( optional ) . | |
Adapter | 60W or more | |
Temperature | Operating temperature : -20°C to + 60 °C (optional: -40°C to + 70 °C ) | |
Size | 205 mm ( length ) x1 40 mm ( width ) x5 5 mm ( height ) (overall dimensions except wall-mounted and external interfaces ) | |
Cooling system | Fanless design | |
Operating system | WIN10, WIN11, Linux | |
Weight | 1.46 kg (bare metal ) , 2.55 kg ( including packaging) | |
Color | The whole machine is gray, and the front and rear panels can be gray or black. | |
