ECS-GM351
YDS
Intel Gemini Lake Refresh
VGA, HDMI
DDR4
SATA, M SATA
YES
Supports 4G
Fanless
232, 422, 485
Supports 4 USB 3.0 ports and 2 USB 2.0 ports.
205 mm ( length ) x1 40 mm ( width ) x5 5 mm ( height )
Operating temperature: -20°C to + 60 °C ( optional: -40°C to + 75 °C)
WIN10, WIN11, Linux
Machine specifications
Technical Information | ||
Processor | Intel® Celeron® N4020 Dual core 1. 1 GHz up to 2.8 GHz , 6 W Intel® Celeron® N4120 Quad-core 1.1 GHz up to 2.6 GHz , 6W Intel® Celeron® J4025 Dual-core 2.0 GHz up to 2.9 GHz , 10 W Intel® Celeron® J4125 Quad-core 2.0 GHz up to 2.7 GHz , 10 W | |
Memory | SO-DIMM DDR4 memory (1.2V, supports up to 8GB ) with a maximum frequency of 2400MHz . | |
Graphics processing | Supports one VGA port with a maximum resolution of 1920x1080 @60Hz Supports one HDMI port with a maximum resolution of 384 0x216 0 @ 60Hz . | |
Network card | Supports 2 REALTEK 8111H 10/100/1000Mbit Ethernet | |
Storage | One mSATA, one SATA 3.0, one MPCIE, with eMMC support (optional) | |
USB | Supports 4 USB 3.0 ports and 2 USB 2.0 ports. | |
Serial port | 4 RS232 (3-wire), 2 RS232 (3-wire ) / RS422 / RS485 | |
IO | Supports 8 GPIOs and 1 SIM card slot (Nano). | |
Sound card | ALC662 High-Fidelity Sound Card (Line-Out , MIC-in ) | |
Power supply | + 12V to + 19V voltage , + 12V is recommended. Power on (default ) , trigger power on ( optional ) . | |
Adapter | 60W or above | |
Temperature | Operating temperature: -20°C to + 60 °C ( optional: -40°C to + 75 °C) | |
Size | 205 mm ( length ) x1 40 mm ( width ) x5 5 mm ( height ) (overall dimensions except wall-mounted and external interfaces ) | |
Cooling system | Fanless design | |
Operating system | WIN10 , WIN11, Linux | |
Weight | 1.46 kg (bare metal ) , 2.55 kg ( including packaging) | |
Color | The whole machine is gray, and the front and rear panels can be gray or black. | |
Machine specifications
Technical Information | ||
Processor | Intel® Celeron® N4020 Dual core 1. 1 GHz up to 2.8 GHz , 6 W Intel® Celeron® N4120 Quad-core 1.1 GHz up to 2.6 GHz , 6W Intel® Celeron® J4025 Dual-core 2.0 GHz up to 2.9 GHz , 10 W Intel® Celeron® J4125 Quad-core 2.0 GHz up to 2.7 GHz , 10 W | |
Memory | SO-DIMM DDR4 memory (1.2V, supports up to 8GB ) with a maximum frequency of 2400MHz . | |
Graphics processing | Supports one VGA port with a maximum resolution of 1920x1080 @60Hz Supports one HDMI port with a maximum resolution of 384 0x216 0 @ 60Hz . | |
Network card | Supports 2 REALTEK 8111H 10/100/1000Mbit Ethernet | |
Storage | One mSATA, one SATA 3.0, one MPCIE, with eMMC support (optional) | |
USB | Supports 4 USB 3.0 ports and 2 USB 2.0 ports. | |
Serial port | 4 RS232 (3-wire), 2 RS232 (3-wire ) / RS422 / RS485 | |
IO | Supports 8 GPIOs and 1 SIM card slot (Nano). | |
Sound card | ALC662 High-Fidelity Sound Card (Line-Out , MIC-in ) | |
Power supply | + 12V to + 19V voltage , + 12V is recommended. Power on (default ) , trigger power on ( optional ) . | |
Adapter | 60W or above | |
Temperature | Operating temperature: -20°C to + 60 °C ( optional: -40°C to + 75 °C) | |
Size | 205 mm ( length ) x1 40 mm ( width ) x5 5 mm ( height ) (overall dimensions except wall-mounted and external interfaces ) | |
Cooling system | Fanless design | |
Operating system | WIN10 , WIN11, Linux | |
Weight | 1.46 kg (bare metal ) , 2.55 kg ( including packaging) | |
Color | The whole machine is gray, and the front and rear panels can be gray or black. | |
